Acrel Intelligent Smart Modbus Motor Protector with RS485 Modbus RTU Ard2f

Basic Info.

Model NO.	ARD2F-25/C+90L
Applicaiton	Coal, Petrochemicals, Smelting Industry
Warranty	2years
Accuracy	Class 1.5
Rated Voltage	AC 380V/AC 660V
Auxiliary Power Supply	AC85V-265V/DC100V-350V
Certificatons	Ce CCC
Frenquency	50Hz/60Hz
Brand	OEM ODM
Product Name	Smart Motor Protector
Transport Package	Fob Shanghai
Specification	160*50*110mm
Trademark	ACREL
Origin	China
Production Capacity	1000PCS/Per Month

Product Description

Product Description

ARD2F Smart Motor Protector
General

ARD series intelligent motor protector (hereinafter referred to as protector) can perform various conditions such as starttimeout, overload, phase failure, unbalance, underload, ground/leakage, blockage, short circuit and external fault during motor operation. Protection, and SOE fault event recording function, convenient for on-site maintenance personnel to find the cause of the fault. Suitable for coal, petrochemical, smelting, electric power, ships, and civil construction. The protector has RS485 remote communication interface, DC 4 ~ 20mA analog output, and PLC, PC and other control machines form a network system. Remote monitoring of motor operation.
Features1.Measurement functions are divided into basic measurement (current parameter) and co-selection measurement (voltage, power, phase sequence, residual current (leakage current);2.Start timeout, overload, stall, block, underload, phase failure, unbalance, residual current (ground/leakage), temperature,3.external fault, phase sequence, overvoltage, undervoltage, underpower, overpower, tE time Motor comprehensive protection function;4. 9-channels DI passive dry node input, signal power supply with built-in DC24V power supply;5.5-channels DO output, which can meet the direct start, star-delta start, autotransformer start, soft start and other starting modes. Real-time remote control "start/stop" operation of the remote master station can be realized through the communication bus;6.It has standard RS485 communication interface and adopts Modbus-RTU and Profibus-DP communication protocol to ensure fast and reliable communication of the host computer;7.It has a DC4-20mA analog output interface and is directly connected to the DCS system to monitor the field devices.
Technical Parameters

Technical data of motor protector ARD2F-25
Auxiliary power supply of protector	AC85V~265V/DC100V~350V, power consumption ≤7VA
Rated working voltage of motor	AC380V/AC660V, 50H/60Hz
Rated working current of motor	1A(0.1 ~9999)	Small specific current transformer
	5A(0.1 ~9999)
	1.6A(0.4A-1.6A)
	6.3A(1.6A~6.3A)
	25A(6.3A~25A)
	100A(25A~100A)
	250A(63A-250A)	Specific current transformer
	800A(250A~800A)
Relay output contactor, rated load capacity	4-way,AC250V, 3A, DC30V, 3A
Switching input	2-way, optical isolation
Communication	RS485 Modbus
Volume of SOE event recorder	8 events
Environment	Working temperature	-10ºC-55ºC
	Storage temperature	-20ºC-65ºC
	Relative humidity	5%-95%, no dew
	Altitude	≤2000m
Class of pollution	2
Protection level	IP20

Rated current of motor protector(A)	current ratio setting	Transformer primary side turns	Setting current Is range(A)	Motor Power(kW)
1	able to set	5	0.1~9999	0.12~440
5		1	0.1~9999	0.12~440
1.6	unable to set	1	0.4~1.6	0.12~0.55
6.3		1	1.6~6.3	0.75~2.2
25		1	6.3~25	3~11
100		1	25~100	15~45
250		1	63~250	55~132
800		1	250~800	160~440
